System Information Development Kit

The System Information Development Kit offers a set of functions that gathers in-deep information about the core components of
a PC : CPU, chipset, memory.

  • Processors topology (number of processors, cores per processor, threads per core).
  • CPU name and number, codename, process, package, stepping, supported instructions sets, cache levels.
  • Real time measurement of each core's internal frequency, clock multiplier, bus speed and rated FSB.

  • Chipset northbridge and southbridge name.
  • Mainboard vendor and model.
  • BIOS vendor, version and release date.
  • Memory type and size.
  • Real time measurement of memory frequency and key timings: CL, tRCD, tRP, tRAS, tRC, CR.
  • Memory module specification (SPD) : size, manufacturer, maximum speed and bandwith (PC-xxxx), standard timings profiles and extended profiles.

Supported Hardwares

Processors
  • Intel® Pentium™, Pentium™ MMX, Pentium™ Pro, Pentium™ II, Pentium™ !!!, Pentium™ !!!-M, Pentium™ 4, Pentium™ 4-M, Pentium™ M, Pentium™ D, Pentium™ XE, Pentium™ Dual Core, Core™ Solo, Core™ Duo, Core™ 2 Duo, Core™ 2 Quad, Core™ 2 Extreme, Celeron™ (P2/P3/P4/PM/CL) and Xeon™ (P2/P3/P4/C2D/C2Q) ; Core™ i3, Core™ i5, Core™ i7, Core™ i7 Extreme ; Atom™ ; Itanium™, Itanium™ 2 ;
  • AMD® Am5x86, K5™, Geode LX, K6™, K6™-2, K6™-III, K6™-2+, K6™-III+, Athlon™ (4, XP, MP), Duron™, Sempron™ (K7/K8), Athlon™ 64, Athlon™ 64 X2, Turion™, Opteron™, Athlon™ FX, Phenom™, Phenom™ II, Athlon™ II ;
  • VIA® C3™ (Samuel, Samuel2, Ezra, Ezra-T, Nehemiah), C7™, C7™-M, Nano™ ;
  • Transmeta® Crusoe™ TM3200, TM5400, TM5500, TM5600, TM5800 ;

Chipsets
  • Intel® i430TX, i440LX, i440FX, i440BX/ZX, i810/E, i815/E/EP/EM, i840, i845, i845E, i845G, i850/E, i845PE/GE, E7205, E7500, E7520, i852, i855, i865P/PE/G, i875P, i915P/G, i915PM/GM, i925X/XE, i945P/PL/G/GZ, i945PM/GM/GT, i955X/XE, P965, Q965, G965, GL960/GM965/PM965, i975X, P35, G33, G31, Q35, Q33, X38, X48, P45, P55, X58, P55, H55 ;
  • VIA® Apollo VP3, Apollo Pro, Apollo Pro +, Apollo Pro 266, KX133, KT133(&A), KT266(&A), KT400(&A), KT600, P4X266(&A), PT880, PT880 Pro, K8T800, K8T890, K8T900, P4M800CE, P4M890, P4M900, CX700/VX700 ;
  • NVIDIA® nForce, nForce2, nForce3, nForce4, nForce4 SLI Intel Edition, GeForce 6100/6150 (nForce 410/430), nForce 520/550/560/570/590, GeForce 7050/7100/7150, 650i, 680i, 740i, 750a/780a, 750i, 780i, 790i ;
  • ATi® RS350, RS400, RS480/RX480, RS482, RD580/RX580, RS600/RD600, RS690, RS700, RD790 ;
  • SiS® 645, 645DX, 648, 648FX, 649, 655FX, 655TX, 656, 662, 735, 756, 761GX, 760, 760GX, 755, 755FX, 741, 741GX, 671/FX/DX/MX ;
  • AMD® AM-751, AM-761, AM-762 (760MP), 780G, 790GX, 890GX ;

Memory Technologies
  • SDR, RDRAM (Rambus®); DDR, DDR2, FB-DDR2, DDR3, DDR4 ;
  • EPP, XMP and AMP extended profiles ;

Compatibility

The System Information Development Kit is provided as a Windows dynamic-linked library (dll) and a set of interfaces for the following programming languages:


  • Microsoft® Visual Basic™
  • Microsoft® Visual C#™
  • Microsoft® Visual C++™

Licensing & Pricing

Please check out our licenses and pricing table for a complete description of our offer and our updates policies, and ask for an 20-days evaluation version.

Please consult the Commercial Use License Agreement for the complete licensing conditions.
